Weight Depend on the goods 45G±2

Type CAT 4 4G Mifi 4G LTE

LCD LCD ONLY yes

User Manual Support yes

Charging batteries The maximum current is 1.5A. The battery is over-discharged and charging is normal at 2.6V. There is no response in the first 3 minutes of charging. 2A charger, fully charged after 2 hours of shutdown. Full voltage 4.32V

Power supply Battery 3000mAh-4.35V

Wireless communication chipset QUALCOMM

WiFi chipset QUALCOMM

CPU model MDM8916

chipset for WiFi /Bluetooth model WCN3620/WCN3660

SIM slot SIM MICRO

USB interface USB-A 2.0

Max. WIFI Users 8 users 2.4GHz

Indicator LED 4G+WIFI+batteries

Radio frequency chip WCN1605L

Main antenna FPC

WIFI antenna 2.4G onboard antenna

LTE band Band 1.3.7.8.20.38.40.41 Frequency bands can be customized

Wireless MIMO technology N/A Single antenna transmit and receive

Wireless transmit power TDD-LTE:21dbm±2dbm

FDD-LTE:21dbm±2dbm

WCDMA :21dbm±2dbm

WIFI band Support 2.4GHz

WIFI MIMO technology Support 802.11b/g/n 1*1

LTE TDD-LTE:Cat4 130 Mbps DL / 35Mbps UL FDD-LTE Cat4 150 Mbps DL / 50Mbps UL Theoretical peaks, related to test environment, bandwidth, and channel settings

WCDMA DL 21Mbp

UL 5.76Mbps

3GPP/3GPP2 protocol LTE FDD/TDD Rel 9 YES

WiFi standard 802.11 b/g/n(1*1 only) YES

WiFi Authentication WPA-PSK/WPA2-PSK default The default authentication method can be customized

Reset button Yes support

Operating temperature -10~ 60° C YES

Storage temperature -45 ~ 85° C YES

Humidity 10%~ 95%

YES
