Intex Online UPS 3KVA 3kva/3kw

• Green Power design for energy saving and environmental protection
• Higher power factor
• Higher efficiency
• Larger charging current
• Can be connected with multiple battery packs in parallel


  Description

  Model	PT-3KS
  Rated Capacity	3KVA/3000W
  INPUT
  Input Formats	L+N+PE
  Rated Input Voltage	208/220/230/240VAC
  Voltage Range	110-300VAC (110-176VAC,280-300VAC power limited)
  Frequency Range	50/60Hz±6Hz,±10Hz (setable)
  Input Power Factor	≥0.99
  Input Harmonic Distortion	≤3% THD(linear load), ≤5% THD(non-linear load) PF=0.8
  OUTPUT
  Output Formats	L+N+PE
  Output Voltage	208/220/230/240VAC
  Output Accuracy	±1%
  Output Frequency	AC mode: same as AC, Battery mode:50/60Hz±1%
  Output Harmonic Distortion	≤1% THD(linear load), ≤3% THD(non-linear load)PF=0.8
  Output Power Factor	1
  Transform Time	AC mode to Batt. Mode:0ms, Inverter mode to bypass mode:4ms
  Load Capacity	Ac Mode:                                                              Battery Mode: 30min@102%-110%Load                                 1min@102%-110% Load 10min@110%-130%Load                                 10s@110%-130%Load 30s@130%-150%Load                                       3s@130%-150%Load 200ms@>150%Load                                           200ms@>150%Load
  MACHINE EFFICIENCY
  AC Mode	Full load efficiency 95.5%@220VAC
  Battery Mode	Full load efficiency 91.5%@96VDC
  Battery Mode	Full load efficiency 91.5%@72VDC
  BATTERY
  Battery Quantity	6*9AH
  Backup Time	Depending on user’s requirement and configuration
  Charge Current	PT1K-10K :1.0A(default), 1-12A(adjustable) External battery back PT1KL-10KL :5.0A(default),1-12A(adjustable)
  WORKING ENVIRONMENT
  Ambient Temperature	0-40˚C
  Ambient Humidity	20%-95% (No Condensation)
  Storage Temperature	-15-60˚C(Battery:0-40˚C)
  Altitude	<1000m, Derating at above 1000m, maximum 4000m, Refer to  IEC62040
  DISPLAY
  LCD	Working mode/load/battery power/input/output etc
  STANDARD & CERTIFICATION
  Standard & Certification:          EN/IEC 61000, EN/IEC 62040, GB/T4943, YD/T 1095, TLC etc
  PHYSICAL
  L*W*H	395*190*325
  Weight(KG)	22.2
  COMMUNICATION INTERFACE
  INTERFACE	1*USB,1*RS232,1*EPO
